| Model No. | Rated Voltage | Communication Module | Power Supply | Max.Load | Min.Load | Dimming Method | Application | Dimension L×W×H (in/mm) |
| LED/Incandescent | LED/Incandescent | |||||||
| ANA042CULR1-1200-R | 120-277V, 50/60Hz | – | Live wire | 1200VA | 5VA | 0-10V | Single-Pole or 3-Way | 4.13×1.73×1.22 /105x44x31 |
| ANA042CULR2-*-1200-R | 120-277V, 50/60Hz | Bluetooth Zigbee Wifi | Neutral and Live wire | 1200VA | 5VA | 0-10V | Single-Pole or 3-Way | 4.13×1.73×1.22/105x44x31 |
| ANA042CULR3-*-1200-R | 120-277V, 50/60Hz | Bluetooth Zigbee | Live wire or Neutral & Live wire | 1200VA | 5VA | 0-10V | Single-Pole or 3-Way | 4.13×1.73×1.22/105x44x31 |
Remark:“*”in model means Communication Module, W- means WiFi, B- means Bluetooth, ZB- means Zigbee.
