Model No. | Charging port | Charging Power | Charging output parameter | |||
PACN020A-2C1A-65W | USB Type-(2C+A) | Max 65W | Single-port charging | Type-C1 | 65W Max. | 5V/9V/12V/15V┄3A,20V┄3.25A |
Type-C2 | 65W Max. | 5V/9V/12V/15V┄3A,20V┄3.25A | ||||
Type-A | 30W Max. | 5V/9V ┄3A, 12V ┄2.5A 20V┄1.5A | ||||
Two-port charging Type-(C1+C2) | Type-C1 | 45W Max. | 5V/9V/12V/15V┄3A,20V┄2.25A | |||
Type-C2 | 20W Max. | 5V┄3A, 9V┄2.2A 12V┄1.67A | ||||
Two-port charging Type-(C1+A) | Type-C1 | 45W Max. | 5V/9V/12V/15V┄3A,20V┄2.25A | |||
Type-A | 18W Max. | |||||
Two-port charging | Type-(C2+A) | 15W Max. | 5V┄3A(shared) | |||
Three-port charging Type-(C1+C2+A) | Type-C1 | 45W Max. | 5V/9V/12V/15V┄3A,20V┄2.25A | |||
Type-(C2+A) | 15W Max. | 5V┄3A(shared) |
