| Model No. | AC Outlet Current | Charging port | Charging Power | Charging output parameter | ||||
|
PAAS040A-2C2A-65W |
Total |
USB |
Max |
Single-port |
Type-A1 | 18W MAX | ||
| Type-A2 | 18W MAX | |||||||
| Type-C1 | 20W MAX | 5V┄3A,9V┄2.2A,12V┄1.67A | ||||||
| Type-C2 | 65W MAX | 5V/9V/12V/15V┄3A,20V┄3.25A | ||||||
|
Two-port |
A1+A2 | A1+A2 | 15W MAX | 5V┄3A (Share) | ||||
| A1+C1 | A1+C1 | 15W MAX | 5V┄3A (Share) | |||||
|
A1+C2 |
A1 | 18W MAX | ||||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
| A2+C1 | A2+C1 | 15W MAX | 5V┄3A (Share) | |||||
|
A2+C2 |
A2 | 18W MAX | ||||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
|
C1+C2 |
C1 | 20W MAX | 5V┄3A,9V┄2.2A,12V┄1.67A | |||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
|
Three-port |
A1+A2+C1 | A1+A2+C1 | 15W MAX | 5V┄3A (Share) | ||||
|
A1+A2+C2 |
A1+A2 | 15W MAX | 5V┄3A (Share) | |||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
|
A1+C1+C2 |
A1+C1 | 15W MAX | 5V┄3A (Share) | |||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
|
A2+C1+C2 |
A2+C1 | 15W MAX | 5V┄3A (Share) | |||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
|
Four-port |
A2+A2+C1+C2 |
A1+A2+C1 |
15W MAX |
5V┄3A (Share) |
||||
| C2 | 45W MAX | 5V/9V/12V/15V┄3A,20V┄2.25A | ||||||
