| Series | Model Number | Wattage (W) |
CDM Wattage Comparison(W) |
CBCP(cd) | Luminous Flux(lm) |
Beam Angle |
Base | M.O.L(mm/in) | M.O.D (mm/in) |
|
| E26 | E27 | |||||||||
| L6PAR30L Ra80 | T-L6PAR30L-30W-COB-12D | 30 | CDM:35 | 31000cd | 3000 | 12° | E26 E27 |
124.8/ 4.91 | 127.8/ 5.03 | 95/ 3.74 |
| T-L6PAR30L-30W-COB-30D | 30 | CDM:35 | 10000cd | 3000 | 30° | |||||
| L6PAR30L Ra90 | T-L6PAR30L-30W-COB-15D | 30 | CDM:35 | 22000cd | 3000 | 15° | ||||
| T-L6PAR30L-30W-COB-35D | 30 | CDM:35 | 7500cd | 3000 | 35° | |||||
| L7PAR30L Ra80 | T-L7PAR30LD-20W-COB | 20 | CDM:30 | 15500cd/15° 11000cd/25° | 2100 | 15°,25°, 35° |
E26 E27 |
115/ 4.53 | 118/ 4.65 | 95/ 3.74 |
| T-L7PAR30LD-26W-COB | 26 | CDM:35 | 16500cd/15° 12000cd/25° | 2600 | 15°,25°, 35° |
|||||
| L7PAR30L Ra90 | T-L7PAR30LD-20W-COB | 20 | CDM:30 | 12000cd/15° 9500cd/25° | 1800 | 15°,25°, 35° |
||||
| T-L7PAR30LD-26W-COB | 26 | CDM:35 | 15000cd/15° 10500cd/25° | 2350 | 15°,25°, 35° |
|||||
| L7PAR38 Ra80 | T-L7PAR38D-26W-COB | 26 | CDM:35 | 23500cd/15° 13000cd/25° | 2600 | 15°,25°, 35° |
E26 E27 |
125.5/ 4.94 | 128.5/ 5.06 | 120/ 4.72 |
| T-L7PAR38D-30W-COB | 30 | CDM:40 | 27000cd/15° 15000cd/25° | 3000 | 15°,25°, 35° |
|||||
| T-L7PAR38D-35W-COB | 35 | CDM:40 | 17000cd/25° | 3500 | 25°,35° | |||||
| L7PAR38 Ra90 | T-L7PAR38D-26W-COB | 26 | CDM:35 | 21000cd/15° 11500cd/25° | 2350 | 15°,25°, 35° |
||||
| T-L7PAR38D-30W-COB | 30 | CDM:40 | 23500cd/15° 13000cd/25° | 2700 | 15°,25°, 35° |
|||||
| T-L7PAR38D-35W-COB | 35 | CDM:40 | 15000cd/25° | 3100 | 25°,35° | |||||
