| Specification | ||||
| Model | L5DL2H-3CCT/5CCT | L5DL3H-3CCT/5CCT | ||
| Size of Product (mm/in) | Φ90×63/Φ3.54×2.48 | Φ112×65/Φ4.41×2.56 | ||
| Cutout (mm) | Φ65-75 | Φ85-95 | ||
| Power | 5W | 7W | 7W | 10W |
| Luminous Flux | 350lm | 500lm | 500lm | 750lm |
| Power Supply | 100-240V,50/60Hz; 220-240V,50/60Hz | |||
| C.C.T. | 3CCT:2700K/3000K/6500K
5CCT:2700K/3000K/4000K/5000K/6500K |
|||
| Ra | 80,90 | |||
| PF | 0.5,0.7,0.9 | |||
| Beam Angle | 100° | |||
| Life | 15000h | |||
| IP Class | IP20 | |||
| Lamp Body Material | PC+Aluminum | |||
| Lamp Cover | Frosted PC | |||
| Color | White | |||
| Warranty | 2years | |||
| Certificate | SAA | |||
