| Specification | |||
| Model | T-L3AMSG2*1AW-24W T-L3AMSG2*1AW-24W-3CCT T-L3AMSG3*1AW-24W |
T-L3AMSG2*3BW-24W T-L3AMSG2*3BW-24W-3CCT T-L3AMSG3*3BW-24W |
T-L3AMSG2*3AW-30W T-L3AMSG2*3AW-30W-3CCT T-L3AMSG3*3AW-30W |
| Size of Product (mm/in) | 222×154×165mm/8.74×6.06×6.50in | 250×154×135mm/9.84×6.06×5.31in | 302×154×135mm/11.89×6.06×5.31in |
| Power | 2×12W | 2×12W | 2×15W |
| Luminous Flux | 1800lm | 2400lm | 2800lm |
| Power Supply | 120V/60Hz | ||
| C.C.T. | 3000K/4000K/5000K/6500K 3CCT: 3000K,4000K,5000K |
||
| Ra | 80 | ||
| PF | 0.7 | ||
| Beam Angle | 60° | 100° | 100° |
| Sensor | Pyroelectric Infrared Sensor (PIR) | ||
| Detection Degree | 150°/180°/270° | ||
| Detection Distance | 52.49ft (16m) | ||
| “On” Duration Time | G2: 5s(Test)/1min/5min/15min 4 stage G3: 5s(Test)/1min/5min/10min//15min 5 stage |
||
| Installation Method | Wire Connection | ||
| Life | 35000h | ||
| Waterproof Rating | Wet Location / IP65 | ||
| Lamp Body Material | PC+Aluminum | ||
| Lamp Cover | Clear PC | ||
| Color | White/Black/Bronze | ||
| Warranty | 3years | ||
| Certificate | ES,ETL,CE,SAA | ||
Remark: “*” in model means Detection Angle, A-means 150°, B-means 180°, C-means 270°.
