| Specification | |||||||
| Model | T-L3A(B)MSG3*1AW | T-L3A(B)MSG3*3BW | T-L3A(B)MSG3*3AW | T-L22AMSG3*2CW | |||
| Size of product(mm/in) | 222x154x165mm/ 8.74×6.06×6.50in |
250x154x135mm/ 9.84×6.06×5.31in |
302x154x135mm/ 11.89×6.06×5.31in |
392×185.5x142mm/ 15.43×7.30×5.59in |
|||
| Power | 24W | 30W | 24W | 30W | 45W | 32W | 45W |
| Luminous Flux | 2000lm | 3000lm | 2400lm | 3000lm | 5000lm | 3500lm | 5000lm |
| Power Supply | 120V/60Hz | ||||||
| C.C.T. | Single CCT : 3000K/4000K/5000K/6500K 5CCT : 2700K/3000K/4000K/5000K/6500K |
||||||
| Sensor | PIR | ||||||
| Detection Angle | 150°/180°/270° | ||||||
| Detection Distance | 52.49ft(16m) | ||||||
| “On” Duration Time | 5s(Test)/1min/5min/10min/15min/Dusk to Dawn 6 stage | ||||||
| Installation Method | Wire Connection / Terminal (Plug-in) | Wire Connection | |||||
| Waterproof Rating | Wet location/IP65 | ||||||
| Certificate | ETL,CE,SAA | ||||||
